Non-Foaming Explosion-Proof Drum Liquid Filling machine V5 300AE

Typical Application

Liquid Filling Machine is mainly used in industries such as coating, printing ink, paint, asphalt, glue, lubricant, petrochemical, fineness chemical etc. It is suitable for filling liquid, ointment products.
V5-300AE Above-surface Explosion-proof Liquid filling machine, filling on surface of drum, apply a variety of non-foaming liquid filling. Unique design of filling device is easy to operate, filling fast, accurately. When in operation, the operator just simply align the bunghole just below the filling valve, pressing [start] button on handle, the machine will automatically tare out and start precision two speed filling. The filling end and filling valve automatically gets outside of drum, drip collecting at bottom of nozzle. Drum is removed and capped.

Features and functions:

■Entire system using explosion-proof standard manufacturing, Explosion-proof grade: EXdiaIIBT4
■The system uses MITSUBISHI/SIEMENS PLC, safe and reliable
■The nozzle is our company’s proprietary design, unarmed quick disassembly, and easy to maintain;
■Seal and soft connection part is made of Teflon, solvent-proof, acid-proof and alkali-poof, long use time.
■Possible precise 2-shift filling and possible to precisely adjust the 2nd shift filling flow volume.；
■Net weight and gross weight, two kinds of filling mode selection, meeting different filling needs;
■The target amount is free to set up, to adapt to a variety of quantitative filling weight range;
■The dual-window display dedicated filling control instrumentation, the target amount of filling volume, the number of pails, the cumulative amount of information can be displayed;
■The filling valve height can be adjusted manually, applicable to different heights of the drums
■Automatically recognize the empty drum tare. No drum not filling；
■Fill tolerance is checked, and if under weight, additional product is added；
■Controller configurates manual button for all the action, and an e-stop push-button, used to prepare special situation；
■30 groups filling parameters for different products can be generated;
■With self-diagnosis, interface testing, digital tuning, anti-vibration setting, computer communication function；
■Using one-button operation: startup – filling valve lower into drum – automatic tare – filling –filling valve retracts ending filling – drips collecting.

Blueprint:
