COMPLETE RECOVERY PLANT- INTECH

Booth- When integrated with Equipment and post filter gives

1/ Automatic mixing of fresh & recovered powder.

2/ Automatic feeding of powder to spray gun.

3/ Automatic on-line sieving.

4/ Prevention of entry of fines in atmosphere.

The coating and recycling system has the carbon coated powder coated spray chamber with the multi-cyclone recovery giving almost 100% powder utilization. It is maintenance free and has a very long life. The powder booth is easy to clean, resulting in a quick colour change and is safe to operate. No powder spillage out of the booth and maximum recovery through the multi-cyclone results in pollution control.

Guarantee of efficiency of 98.5% with a very long life gives the Multicyclone an edge over other powder recovery systems. The high velocity of powder in the multicyclone reduces powder sticking, so cleaning time is negligible.

98,5% efficiency of the Multicyclone helps in maximum ultilization of chargeable powder. But to comply with Pollution Control Laws, the 1,5% powder fines are required to be arrested. The post filter arrests this powder and gives out breathable air.

A number of filter cartridges are mounted inside the sealed metallic chamber. The air enters the chamber and the filteration occurs “outside in”. Periodic purge removes the powder and clean the cartridge. Clean air is given out through the blower outlet.
